| Description | 25T | 60T | 110T | 160T | 250T |
|---|---|---|---|---|---|
| Slide Stoke (mm) | 80 | 120 | 160 | 120 | 220 |
| SPM (nos) | 70~100 | 50~80 | 35~70 | 30~55 | 25~45 |
| Max Die Set Height (mm) | 250 | 400 | 450 | 550 | 600 |
| Die Height Adjustment (mm) | 75 | 100 | 120 | 120 | 130 |
| Slide Area (LRxFB) (mm) | 360x250 | 480x400 | 620x520 | 700x580 | 880x700 |
| Bolster Area (LRxFB) (mm) | 710x410 | 870x520 | 1100x680 | 1260x760 | 1500x840 |
| Air Pressure (bar) | 6 | 6 | 6 | 6 | 6 |
| Height of Bolster Surface (mm) | 755 | 830 | 860 | 900 | 1050 |
| Main Motor (kw) | 3.0 | 5.5 | 11.0 | 15.0 | 22.0 |
